Vehicle Tracking Systems: How Hardware, Network and Platform Fit Together

Nobody buys “a vehicle tracking system”. They buy three things that have to work together — a device, a connection and a platform — usually from different places, and usually without anyone owning the seams between them.

Discuss a tracking system

Start with the decision

Three layers to settle in order

Start with what the asset exposes

The device sets the ceiling for what can ever be measured.

Key point: Power, interface and environment are per asset class.

This page is the overview. If you already know which assets you are tracking, jump to trucks, company vehicles and LCVs, equipment and machines, trailers or containers.

Each layer is usually bought from a different supplier, and failures often happen at the joins rather than inside any one layer.

Module

A tracking system is three layers

Layer	What it decides	What typically goes wrong
Device	What can be measured: position, machine data, sensors or driver identification.	Chosen for one asset type and forced onto the rest of the fleet.
Connectivity	Whether data gets out in every market for as long as hardware lives.	A cellular generation retires or roaming was never checked.
Platform	Whether data becomes something a person acts on.	Field mapping is poor, so columns are empty or wrong later.

Delivery and long-haul

Layer 1 — the device

The device sets a ceiling. No platform configuration can produce data the hardware never collected, and no firmware update can add an interface the vehicle does not expose.

Is there permanent power? If not, it is a battery device and the reporting strategy changes — see non-powered asset tracking.
What does the asset expose? CAN/J1939, serial, digital inputs or nothing. This is a per-model question.
What will actually be used? Capability nobody looks at is cost without benefit.

Buyer checks

Layer 2 — connectivity

Generation and bands: check the countries the asset operates in and their shutdown roadmaps.
Roaming: cross-border operations need usable networks in every country entered.
Volume: reporting interval drives data cost; use the data usage calculator before choosing a SIM plan.
Behaviour offline: confirm whether the device logs and forwards when coverage returns.

Layer 3 — the platform

Protocol and field mapping determine whether readings become useful decisions. Confirm whether the model can be pointed at the intended endpoint and whether the platform can decode the required fields.

The longest-term commitment is often made at the platform layer because changing platforms later can mean changing hardware. Keep the data path open before the order.

C003F

An expandable vehicle terminal for sensor and driver-identification inputs.

Explore C003F

A7C

A general vehicle tracker for company and logistics fleets.

Explore A7C

A300

An industrial gateway when the asset exposes machine data or CAN/J1939.

Explore A300

Vehicle sample validation

Choose by asset, not by brand

If you are tracking…	Start here
Trucks and haulage	GPS trackers for trucks — delivery versus long-haul.
Company cars, vans and LCVs	Company vehicles and LCVs.
Machines and plant	GPS trackers for equipment and plant machinery trackers.
Trailers	Trailer GPS tracking.
Shipping containers	Container tracking.
A mixed fleet	Mixed fleet telematics — two or three device classes, one platform.

Tracker selection check Data usage calculator Blank field confirmation sheet

Commercial terms

Commercial terms worth settling first

Specification	Value
Minimum order	Custom orders start from 100 units. Samples and small validation batches are handled separately.
Lead time	Confirmed by model, configuration and order quantity.
Warranty	12-month limited warranty from the shipment date shown on the commercial invoice. DOA within 30 days is handled under the existing order terms.
Certification	Documents are available for selected models; applicable marks are confirmed for the specific model and destination market.
Reply time (written)	We reply within one working day.

Frequently asked questions

Choosing the hardware

What is a vehicle tracking system?

Three layers working together: a device, a cellular connection and a platform that turns readings into something a person acts on. Most problems occur at the joins.

Which layer should be chosen first?

Start from what the fleet needs to know, then the assets, device, connectivity and platform. Choosing hardware before knowing what vehicles expose is a common mistake.

Can we keep our existing platform and change only the hardware?

Often yes, provided the device can be pointed at the endpoint and speaks a protocol the platform can decode. Confirm it per model.

Why does reporting interval matter so much?

It drives data volume, SIM cost and, on battery devices, how long the unit lasts.

What happens when a cellular generation is switched off?

Devices built only on that generation stop reporting in the affected market. Check the roadmap against actual operating countries.

Do we need one device type for the whole fleet?

Usually not. Two or three device classes on one platform is normal for a mixed fleet.

Ordering and support

What is the minimum order quantity?

Custom orders start from 100 units. Samples and small validation batches are handled separately.

How long is the lead time?

Confirmed by model, configuration and order quantity.

What warranty applies?

A 12-month limited warranty from the shipment date shown on the commercial invoice.

Do you supply certification documents?

Certification documents are available for selected models. Which marks apply is confirmed for the specific model and destination market.

Tell us the asset mix, the markets they run in and the platform you want to keep.
